Semi-Metallic Gaskets

CorrLock™ Gasket

The Lamons CorrLock gasket focuses on the reliability and safety of maintaining a tight seal in hydrogen applications. As we step into the energy transition, these gaskets are becoming more in-demand for critical sealing. Lamons has answered the call by identifying a special material with low permeability for hydrogen, and with the Corrukamm trusted design, it has provided a proven seal.

  • Seal Element: CorruKamm with Proprietary Thermo-Plastic sealing material
  • Pressure Class: Class 150-2500 (150, 300, 600, 900, 1500, 2500), or custom if needed
  • Size Range: ½” to 20”
  • Temperature Range: -253°C (-423°F) to 260°C (500°F)
  • Secondary Kammprofile sealing area faced with Flexible Graphite
